R20/500 230v Electric Gate Motor

Description

Electric Motor Features

• Reliable: due to its planning and design it allows for optimal noise reduction by reducing the number of moving parts.
• Easy: to install thanks to simple electrical connections and suitable fixing plates.
• Movement: comfortable and easy thanks to the electrical stop on the opening.
• Management: available with a control unit with two H70/200AC motors and complete with a convenient key release lever.

Technical Detail:

Power: 230V AC 50Hz
Power rating: 200 W
Max thrust: 2500 N
Frequency of use: 40%
Motor thermal protection: 140C
Operating temperature: -20+55C
Protection level: IP 43
Stroke: 520 mm
Manoeuvre speed: 1,66 cm/s
Opening time: 27 s
Incorporated condenser: 15 ?F
Maximum dimension (mm): H165xW120xL1088,5
Encoder: –
Limit switch: Microswitch in opening
(optional in closing)
Always included: Kit 3 hinge plates long
to weld.(KT205)
1 microswitch.
Reductor Type: Irreversible
