Unmonitored Double Standard Magnet

Description

Operating voltage 12~24Vdc
Aluminium
Holding force up to 1200lbs x 2 (545Kg x 2)
Fail-Safe (Power to Lock)
Surface Mounted
Unmonitored

Magnetic Lock Technical Specification:

Voltage tolerance: 15%.
Current draw: 500mA at 12Vdc, 250mA at 24Vdc (at temperature 20?C).
Operating temperature: -10~55?C (14 to 131?F).
Lock’s surface temperature: Current temperature 20% (when power is on).
Humidity: 0~95% non-condensing.
Special Zinc finishes for magnet and armature plate.
Weight: 8.0kg (approx).
